2+1/2 Turn, 2.5mm thick, Black Zinc Coated Door Handle Springs plus Circlips (Available in packs of 10 and 20)
Currently we are not accepting orders on this website, but you can still order most of our products on Amazon.co.uk. (Just Google 'Northern DIY Amazon Storefront'). We will recommence selling on the website later in the year. You are welcome to use this website for instructions and product specifications, but we are currently unable to answer technical queries unless it is with regards to an order you have previously placed.
2+1/2 Turn, 2.5mm thick, 28mm diameter, Black Zinc Coated Door Handle Springs plus Circlips.
The circlips have an internal diameter of 13.8mm and are intended to fit a 15mm shaft with a 14.3mm groove machined into it. This is the standard size used in the vast majority of door handles. They are external circlips (so called because they fit to the outside of a shaft). They should be removed and replaced using external circlip pliers.
The springs are zinc coated followed by a black passivating coating. It is not a simple cosmetic 'blackened' finish which offers little or no corrosion resistance. The spring is made from wire with a cross section of 2.5mm X 1.2mm giving the handle a positive feel. Please see additional photo for detailed dimensions. This type of spring is used in many Carlisle Brass Door Handles, but please check the dimensions against your broken spring before ordering. Available in packs of 10 and 20.
Note - If you have a requirement for a handle with a lighter feel we also have a 2.5mm thick (uncoated) spring made from a thinner gauge of wire. Please send us a message after placing your order if you would like us to substitute these weaker springs in place of our standard spring.
